Yanzeo SR691 SR692 SR693 UHF RFID Writer Reader 10M Long Distance Outdoor IP67 9dbi Antenna WIFI RS232/RS485/Wiegand RJ45 UHF Integrated Reader

● 9M Long Range UHF Integrated Reader

● High Performance Yanzeo RFID Chip

● RS232/RS485/Wiegand 26 RJ45(Only SR692)

● Waterproof, Durable ,Rugged UHF RFID Reader

● Easy To Develope And Deploy Using Http

Availability: In stock

Call for price.

* Required Fields

Downloads
Details
Details

Yanzeo SR691:Serial Port

Yanzeo SR692:Network Port

Yanzeo SR693:Wifi+Serial+Network Port

Yanzeo is a High Performance UHF integrated reader for long range operation. Compact Reader with integrated 9dBi circular polarized UHF Far Field antenna,.Based on proprietary efficient digital signal processing algorithm,the reader is capable of up to 10m Read Range and 3m Write Range.

The reader operates in frequency range of 902MHz~928MHz design to read ISO18000‐6C and ISO18000‐6B protocol ID Tag.

The reader can be widely applied in many RFID application systems such as logistics, access control, and anti-counterfeit and industrial production process control system.

Features:

  • Self-intellectual property

  • Max reader range 10m

  • Durable and cost effectives

  • All frequency band in the world available Compatible with EPC G2(ISO 18000-6C) or ISO18000-6B

  • Water and dust proof, anti-interference, can work under thunder and light,IP55 Splash Proof

  • Easy to install with enclosure up-and-down adjustable bracket

Area of Application:

  • Automotive and Transportation

  • Supply Chain and Super Mart

  • Parking lot Management

  • School, Library

  • Contact-less Payment

  • Logistic Management

  • Boarder and Access Control

  •  Asset Tracking

  • Time&Attendance Management

  • Anti‐counterfeit

  • Farm and Animal Tracking

  • Club and Hospital

Specification:

Functions

Operating Frequency

International(920~925MHz)

USA(902~928MHz)

Others(Customized Tag)

Protocol

ISO18000‐6C(EPCGEN2)

ISO18000‐6B

Frequency Hopping  Mode

Fixed Frequency Band and FHSS Software Programmable

Antenna

9dBi circular polarize antenna (Integrated)

Output Power

0dBm~30dBm(Adjustable)

Read/Write Range

Max Read Range:10m,  Max Write Range:3m                    Distance depends on Reader&Antenna output Power

Operating Mode

Master‐Slave Mode(Online Mode)

Time Scheduled Modes

Trigger Mode

Connecting Ports

Power

12V

Communication Port

RS‐232

Wiegand Interface:Wiegand26&Wiegand34Supported

RS‐485

10/100M Ethernet,GPRS.WIFI(for Customized Model only)

Trigger

1xTriggerLevelInput

General Purpose

2xGPIO

Operating Environment

Operation

-20℃~+60℃

Storage

-45℃~+85℃

Physical Parameter

Dimension

227mm×227mm×60mm

Weight

1.8Kg

Accessories

Power Supply

AC110~220V/DC+12V

Cables

Power Cable

RS232SerialCable

Brackets

Pole Mount Adapter

Software Pack(Optional)

API Software Development Kits complete with VB,C#Sample Program
