SE965 20-70965-02 Scan Engine Symbol Motorola MC45 MC32N0 MC92N0 SE965 1D Laser Scan Engine
● With good reliability and durability. ● Adaptive barcode scanning range. ● Application flexibility in various industries. ● Support data collection technology in complex environment. ● Programmable scan can be custom developed.
Availability: In stock
Call for price.
Details
Details
Product Type: Laser Scan Engine
Regulations
Electrical safety: UL 60950-1, EN/IEC60950-1, EN/IEC 60825-1
Laser Classification: Intended for use in CDRH Class II/IEC, Class 2 devices
Drop specification: 2000 g
Working current: 78 mA typical
Light resistance: 8000 Ft Candles (86,111 Lux)
Working temperature: -30℃ to 60℃
Power supply voltage: 3.3V ± 10%
Performance parameter
Anti-decoding: Decoded
Scan mode: single line
Supported interfaces: SSI Control over TTL Serial on a 12-pin ZIF connector
Scanning angle: Wide (default): 47° (typical); Medium: 35° (typical); Narrow: 10° (typical)
Scan rate: 104±12 scans/sec (bidirectional)
Decoding ability: 1D
Physical parameter
Size: 11.75mm H x 21.6mm W x 15.5mm D
Weight: 7.6g
Other features
1. Large working range from near contact to 200 in. /508 cm
2. Small and lightweight
3. Patented Liquid Polymer scan element with lifetime warranty
4. Die cast zinc chassis and single board construction
5. 104 scans per second
6. Programmable scan angle
7. Bright scan line and enhanced aim mode
8. Built-in remote system performance monitoring
9. Low power consumption
Reviews
Tags
You may also be interested in the following product(s)
![DT-930M51E For CASIO DT930 Data Collector Terminal Barcode Scanner High-Performance Scanner]()
DT-930M51E For CASIO DT930 Data Collector Terminal Barcode Scanner High-Performance Scanner
