Yanzeo EW6 2D Wireless Industrial Barcode Scanner with Storage Charger Base Industrial Bar Code Reader

Symbologies

1D :EAN-8,EAN-13,UPC-A,UPC-E,Code 39,Code 93,Code 128,EAN128,Codabar,Industrial 2 of 5,Interleave 2 of 5,Standard 25,Matrix 2 of 5,MSI,GS1

2D :PDF417,MicroQR,DataMatrix,QR,HanXin,Aztec

Depth of Field

Tested

Code

Minimum

Maximum

6.6mil

code39

5cm

8cm

13mil

EAN13

6cm

20cm

15mil

DM

4cm

14cm

15mil

QR

2cm

16cm

15mil

PDF417

6cm

18cm

System Compatibility

Android OS, Windows XP , Windows 7, Windows 8, Windows10,MAC,IOS,Linux

Scan Pattern

Automatic induction scan, Continuous scan, Manual key scan

Keyboard support

American

Decode Accuracy

Code 39 6.6mil

Code Available

1D, 2D barcodes on paper, film or screen

Scanning Speed

130 Times/Second

Storage Quantity

1927

Symbol Contrast

20%

Scanning Angle

Horizontal: 72° Vertical:82° Rotated:360°

Secondary Development

Not Supports

Barcode Output Editing

Not support adding prefix and suffixes

Transmission Range

The open space 200 meters

Wireless technology

433MHz

Indicator Light

Receiver

After power on, the red light flashes for 15 seconds and then keeps lighting. When match or upload successfully, blue light flashes

scanner

Red&Blue LED,red light power tips, blue light connection tips

Buzzer

Start Tips,Decoding success tips

Button

Trigger scan

Environment Parameters

Drop

Design to withstand 2 m drops to concrete 5 times

Environmental Sealing

IP54

Working Temperature

-20-55degree

Conserve Temperature

-20-60degree

Working Humidity

5-95% Non-Condensed

Conserve Humidity

5-95% Non-Condensed

Environment Light

0-120000LUX

Physical Parameters

Net Weight

151g

Packing Weight

472g

Host Size(L*W*H)

171mm* 72mm*97mm

Packing Size(L*W*H)

240mm*140mm*90mm

Communication

USB

Data line length

150CM(+/-3CM)

Battery capacity

1800MAH

Certification

CE,FCC,ROHS,IEC60950 ,IEC62471, EN55022, EN55024, EN61000-3, IEC62321 EN60950, EN60529
