Looking for a fast, hands-free barcode scanning solution that performs reliably in demanding environments? The YANZEO YS868 offers powerful omnidirectional 1D barcode scanning, wide depth of field, and durable desktop construction—making it a smart choice for retail counters, logistics centers, and factory production lines.
Overview
The YANZEO YS868 Laser Flatbed Desktop Barcode Scanner is engineered for efficiency, accuracy, and long-term performance. With a 20-line omnidirectional optical grating and automatic scanning mode, it quickly detects and decodes 1D barcodes from any angle. Whether you're managing high-volume checkout lines or scanning items on an assembly line, the YS868 provides fast, stable barcode recognition every time.
Key Features
Ultra-Fast Omnidirectional Scanning
The 20-line grating system ensures quick and accurate scanning from any orientation, eliminating the need to manually align barcodes.
Strong Decode Capability
Reads all standard 1D barcodes, including those that are poorly printed, scratched, or smudged.
Wide Depth of Field
Optimized to read barcodes at various sizes and distances:
4mil: 10–50mm
5mil: 0–90mm
10mil: 0–220mm
13mil: 0–240mm
20mil: up to 300mm
Note: Actual performance may vary depending on environment and barcode quality.
Automatic Hands-Free Operation
Scans automatically when a barcode enters the detection zone—no need for manual triggers, ideal for high-throughput applications.
Flexible Interface Options
Standard USB plug-and-play with optional RS232 interface for advanced system integration.
Technical Specifications
| Specification | Details |
|---|---|
| Model | Yanzeo YS868 |
| Scan Technology | 1D Laser, Omnidirectional |
| Scan Pattern | 20-line optical grating |
| Barcode Types | All standard 1D symbologies |
| Depth of Field | Up to 300mm (depending on barcode size) |
| Scan Trigger | Automatic (hands-free) |
| Interface | USB (Standard), RS232 (Optional) |
| Dimensions | 5.91 x 5.91 x 2.76 inches |
| Weight | 1.63 lbs (740g) |
| Construction Material | ABS Plastic |
| Operating System | Windows-compatible (plug-and-play) |
| Certifications | ISO-9001 Certified Manufacturing |
Typical Applications
Retail checkout counters
Logistics and warehouse inventory management
Factory production line tracking
Healthcare and pharmacy POS
School and library systems
Office automation and asset tracking
Why Choose YANZEO YS868
The YS868 combines scanning accuracy, fast performance, and a robust desktop design. Its automatic hands-free operation reduces manual labor and increases throughput, making it ideal for barcode-intensive environments. Whether you’re managing a retail store, processing inventory, or tracking components on a line, this scanner offers dependable results day after day.
What’s in the Box
Yanzeo YS868 Barcode Scanner
USB Cable (Standard Interface)
Quick Start Guide
User Manual
Note: RS232 version available upon request.
Get Started Today
Enhance your scanning efficiency and streamline your operations with the YANZEO YS868 Barcode Scanner.
Visit www.yanzeo.com for more product details or to request a quote.
